CABLE COVER ASSEMBLY (CABLE STORAGE). |
|
||
| ||||||||||
|
|
 ARMY TM 3-6665-329-13&P
AIR FORCE TO 11H2-18-1
This task covers:
Removal.
a.
Installation.
b.
INITIAL SETUP
Tools:
Electronic equipment tool
kit TK-105/G
Removal
a.
(1) Remove lid (para 3-11b steps 1 thru 3).
(2) Unscrew screw (1) and open cable cover assembly (2).
(3) Remove three screws (3), nuts (4), and lockwashers (5).
Installation.
b.
(1) install cable cover assembly (2) on hinge using three screws (3), lockwashers (5)
and nuts (4).
(2) Close cable cover assembly (2) and secure with screw (1).
(3) Install lid (para 3-11c step 20).
3-97
Change 2
|
|
