REMOVE/REPLACE CONTROL PANEL INDICATOR LAMP

TM 11-7035-203-23

4-16. REMOVE/REPLACE CONTROL PANEL INDICATOR LAMP

INITIAL SETUP

Common Tools

Materials/Spare Parts

q Tool kit

q Control panel lamp(s)

Remove

NOTE

Follow these procedures to remove/

replace any of the indicator bulbs.

There are two bulbs in the HALF

CYCLE/FULL CYCLE indicator.

1. POWER off.

2. Pull off indicator cap. If

necessary, pry up using small,

flat-blade screwdriver.

3. Pull out lamp.

Replace

1. Push new lamp into socket.

2. Push on indicator cap.

3. POWER on.

4. Test lamp by pressing indicator cap

of replaced lamp.

4-27
