GROUP 02: PANEL ASSEMBLY, TEST SET FIGURE 3, TEST SET PANEL ASSEMBLY (CONT) |
|
||
| ||||||||||
|
|
 ARMY TM 3-6665-329-13&P
AIR FORCE TO 11H2-18-1
SECTION II. REPAIR PARTS LIST
(1)
(2)
(3)
(4)
(5)
(6)
ITEM
SMR
PART
NO.
CODE
FSCM
NUMBER
DESCRIPTION AND USABLE ON CODE
QTY.
58
PAFZZ
96906
MS51957-15
SCREW, MACHINE
12
59
XDFZZ
81361
B5-15-8257
BRACKET, CONN, MTG
2
60
PAFZZ
96906
MS35649-224
NUT, PLAIN, HEX
6
61
PAFZZ
96906
MS35338-134
WASHER, LOCK
6
M15733/23-
62
PAFZZ
81349
0060
FILTER, RF
2
63
PAFZZ
96906
MS51959-29
SCREW, MACHINE
3
64
XDFZZ
81361
D5-15-8240
COVER ASSY, CABLE STORAGE
1
65
PAFZZ
81361
D5-15-8246
SENSOR, TEMPERATURE (INLET TEMP)
1
66
PAFZZ
96906
MS51957-16
SCREW, MACHINE
4
67
XDFZZ
81361
D5-15-8208
HOUSING, SUBASSEMBLY
1
68
XAFZZ
81361
E5-15-8235
HOUSING, CABLE
1
69
PAFZZ
81361
D5-15-8251
CIRCUIT CARD ASSEMBLY
1
70
PAFZZ
96906
MS51957-13
SCREW, MACHINE
2
71
PAFZZ
96906
MS51859-3
SCREW, MACHINE
4
72
PAFZZ
96906
MS3115-14W
CONNECTOR, DUMMY
1
73
XDFZZ
81349
37TB4
TERMINAL BOARD (TB2)
1
74
PAFZZ
96906
MS51957-31
SCREW, MACHINE
8
CABLE ASSY, POWER, ELECTRICAL,
75
PAFZZ
81361
D5-15-8243
BRANCHED (DETECTOR POWER)
1
76
XDFZZ
81361
B5-15-8263
LATCH, BRACKET ASSY
1
CABLE ASSY, SPECIAL PURPOSE
77
PAFZZ
81361
D5-15-8242
ELECTRICAL, BRANCHED (CHASSIS TEST)
1
E-28
CHANGE 2
|
|
