GROUP 02: PANEL ASSEMBLY, TEST SET FIGURE 3, TEST SET PANEL ASSEMBLY (CONT) |
|
||
| ||||||||||
|
|
 ARMY TM 3-6665-329-13&P
AIR FORCE TO 11H2-18-1
SECTION II. REPAIR PARTS LIST
(1)
(2)
(3)
(4)
(5)
(6)
ITEM
SMR
PART
NO.
CODE
FSCM
NUMBER
DESCRIPTION AND USABLE ON CODE
QTY.
39
PAFZZ
96906
MS25089-3C
SWITCH, PUSH
2
40
PAFZZ
96906
MS24524-23
SWITCH, TOGGLE
1
*
41
PAFZZ
72619
521-9248
LIGHT, INDICATING, LED
1
42
PAFZZ
96906
MS24523-22
SWITCH, TOGGLE
4
43
PAFZZ
96906
MS24523-27
SWITCH, TOGGLE
1
44
PAFZZ
96906
MS35338-98
WASHER, LOCK
3
45
PAFZZ
96906
MS51957-34
SCREW, MACHINE
2
46
PAFZZ
96906
MS51957-32
SCREW, MACHINE
1
47
PAFZZ
81361
D5-15-12551
CIRCUIT CARD ASSY
1
48
PAFZZ
81349
M39024/10-08
JACK, TIP (YELLOW)
5
49
PAFZZ
81349
M39024/10-03
JACK, TIP (BLACK)
2
50
PAFZZ
81349
M39024/10-02
JACK, TIP (RED)
1
51
PAFZZ
96906
MS91528-1F2B
KNOB
2
52
PAFZZ
81361
C5-15-12557
SWITCH, ROTARY
1
53
PAFZZ
96906
MS51957-5
SCREW, MACHINE
2
54
PAFZZ
81361
E5-15-8221
WIRING HARNESS, BRANCHED
1
55
PAFZZ
96906
MS35649-244
NUT, HEX, PLAIN
22
56
PAFZZ
96906
MS35338-135
WASHER, LOCK
4
57
PAFZZ
96906
MS51957-18
SCREW, MACHINE
4
CHANGE 3
E-27
|
|
