![]() TM 11-7035-203-23
S C H E M A T I C DIAGRAMS
D-1 . GENERAL
Appendix D provides information to be used if troubleshooting procedures in this
manual fail to help you isolate a fault. You can use common procedures to check
wire connections and circuits.
D-2. DIAGRAMS
Foldout FO-1 illustrates the pin numbers and circuitry of the tape cleaner
including:
q Control
switch connectors (P1/J1)
Ac input connectors (P1/J2)
q
q Photocell
connectors (P1/J3)
q Fan
connectors (P1/J4)
q Reel
motor supply brake connectors (P2/J6)
q Reel
motor tape-up brake connectors (P3/J5)
D-1/(D-2 blank)
|
