Page Title:
REMOVE/REPLACE REEL MOTOR CAPACITOR |
|
||
| ||||||||||
|
|
 TM 11-7035-203-23
INITIAL SETUP
Materials/Spare Parts
Common Tools
q Tool kit
q Wire tags
q Pen or pencil
Remove
1. Open tape cleaner (para 4-11).
20 Cut tie wrap from around capacitor.
3. Tag, then disconnect leads.
4. Remove screw from both mounting
brackets.
5. Take off mounting brackets.
6. Lift out capacitor.
Replace
1. Place capacitor in position.
Position mounting brackets on
capacitor.
2. Replace and tighten screw in both
brackets.
3. Replace tie wrap.
4. Replace leads.
5. Close tape cleaner (para 4-11).
|
|
