REMOVE/REPLACE REEL MOTOR CLUTCH |
|
||
| ||||||||||
|
|
 TM 11-7035-203-23
INITIAL SETUP
Common Tools
Materals/Spare Parts
Personnel Required
q Tool kit
q Pen or pencil
q Two
q Tags
Remove
1. Remove reel assembly motor belts
from both motors (para 4-20).
2. Tag and remove wires from ac power
terminal strip.
3. Tag and remove connectors at J1 thru
J6 from printed circuit board.
4. Remove screws from mounting plate.
|
|
