TM 11-7035-203-23

1-14. EQUIPMENT DATA

Weight and dimensions:

Weight 85.0 lb

(34.1

kg)

Height 27.3 in. (69.3

cm)

24.0 in. (61.0

Width

cm)

16.2 in. (41.1

cm)

Depth

Operating environment:

Temperature 65 F to 85 F (18 c to 29 C)

Relative humidity 20% to 90% (noncondensing)

Electrical requirements:

Voltage 110 V ac to 125 V ac

Frequency 60 Hz

Tape capacity:

1/2 in. wide tape on 10-1/2 in. diameter reel.

Cycle time:

Approximately 5-3/4 minutes for full cycle cleaning (average

speed 150 ips).

Reel positioning and retaining:

Snap lock hubs.

Tape transport control:

Photocell for BOT and EOT detection for automatic stop and

reversal of tape.

Tape guiding:

Precision roller guides and all tape paths precisely alined.

1-5/(1-6 blank)
