SECTION II
TM11-6625-2941-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM
SMR
PART
NO
CODE
FSCM
NUMBER
DESCRIPTION AND USABLE ON CODE (UOC)
QTY
GROUP 0105 CIRCUIT CARD ASSEMBLY
A12 ("A-B" CHANNEL INPUT)
FIG 6
1
PADZZ
72982
8121M112X7R0103M
CAPACITOR,FIXED,CER  USED ON SERIAL
11
NO 1828A00001 THROUGH 1908A99999
2
PADZZ
96906
MS75085-19
COIL,RADIO FREQUENC
2
3
PADZZ
81349
M39014/01-1593
CAPACITOR,FIXED,CER
2
4
PADZZ
81349
M39014/20-0109
CAPACITOR,FIXED,CER
2
5
PADZZ
28480
0160-4423
CAPACITOR,FIXED,CER
2
6
PADZZ
81349
M39014/23-0313
CAPACITOR,FIXED,CER
2
7
PADZZ
56289
196D686X9006KA1
CAPACITOR,FIXED,ELE  USED ON SERIAL
3
NO 1828A00001 THROUGH 1908A99999
7A
PADZZ
28480
5040-5112
EXTRACTOR,ELECTRICA
1
7B
PADZZ
73957
GP24-063X250-12
PIN,GOOOVED,HEADLES
1
8
PADZZ
81349
CC22CJ3R3C
CAPACITOR,FIXED,CER  USED ON SERIAL
2
NO 1828A00001 THROUGH 1908A99999
8
PADZZ
28480
0160-2242
CAPACITOR,FIXED,CER  USED ON SERIAL
1
NO 1828A00001 THROUGH 1908A99999
8
PADZZ
81349
CC20CJ3R0C
CAPACITOR,FIXED,CER  SELECT AT TEST
1
8
PADZZ
28480
0160-2246
CAPACITOR,FIXED,CER  SELECT AT TEST
1
11
PADZZ
72982
8131-500WR5R0473
CAPACITOR,FIXED,CER
2
K
12
PADZZ
72136
RDM15F301F3C
CAPACITOR,FIXED,MTC
2
13
PADZZ
18796
8101A100C0G0479C
CAPACITOR,FIXED,CER
1
16
PADZZ
56289
196D106X9025KA1
CAPACITOR,FIXED,ELE
2
17
PADZZ
18796
8111A200C0G0100J
CAPACITOR,FIXED,CER  USED ON SERIAL
1
NO 1828A00001 THROUGH 1908A99999
18
PADZZ
96906
MS14046-5
COIL,RADIO FREQUENC
2
19
PADZZ
81349
RNC55K2370FS
RESISTOR,FIXED,FILM  USED ON SERIAL
2
NO 1828A00001 THROUGH 1908A99999
20
PADZZ
81349
RCR07G821JS
RESISTOR,FIXED,COMP  USED ON SERIAL
2
NO 1828A00001 THROUGH 1908A99999
21
PADZZ
81349
RCR07G100JS
RESISTOR,FIXED,COMP
2
22
PADZZ
16845
1000-412-12
RESISTOR,FIXED  USED ON SERIAL NO
2
1828A00001 THROUGH 1908A99999
23
PADZZ
81349
RCR07G102JS
RESISTOR,FIXED,COMP  USED ON SERIAL
1
NO 1828A00001 THROUGH 1908A99999
24
PADZZ
32997
3329WT22-102
RESISTOR,VARIABLE,N  USED ON SERIAL
2
NO 1828A00001 THROUGH 1908A99999
25
PADZZ
16845
1000-409-16
TRANSISTOR  USED ON SERIAL NO
2
1828A00001 THROUGH 1908A99999
26
PADZZ
80294
3329W1-101
RESISTOR,VARIABLE, N  USED ON SERIAL
2
NO 1828A00001 THROUGH 1908A99999
27
PADZZ
81349
RNC50K5110FS
RESISTOR,FIXED,FILM  USED ON SERIAL
2
NO 1828A00001 THROUGH 1908A99999
28
PADZZ
81349
RCR07G561JS
RESISTOR,FIXED,COMP  USED ON SERIAL
2
NO 1828A00001 THROUGH 1908A99999
29
PADZZ
81349
RLR05C5620FS
RESISTOR,FIXED,FILM  USED ON SERIAL
2
NO 1828A00001 THROUGH 1908A99999
6-1
