SECTION II
TM11-6625-2941-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM
SMR
PART
NO
CODE
FSCM
NUMBER
DESCRIPTION AND USABLE ON CODE (UOC)
QTY
GROUP 0104 CIRCUIT CARD ASSEMBLY
A8 ("C" CHANNEL INPUT)
FIG 5
1
PADZZ
72982
8121M112X7R0103M
CAPACITOR,FIXED,CER  USED ON SERIAL
7
NO 1828A00001 THROUGH 1908A99999
2
PADZZ
81349
M39014/23-0334
CAPACITOR,FIXED,CER  USED ON SERIAL
1
NO 1828A00001 THROUGH 1908A99999
3
PADZZ
81349
M39014/01-1593
CAPACITOR,FIXED,CER  USED ON SERIAL
6
NO 1828A00001 THROUGH 1908A99999
4
PADZZ
28480
0160-3878
CAPACITOR,FIXED,CER  USED ON SERIAL
7
NO 1828A00001 THROUGH 1908A99999
5
PADZZ
28480
05303-80001
COIL,RADIO FREQUENCY  USED ON SERIAL
1
NO 1828A00001 THROUGH 1908A99999
6
PADZZ
81349
M39014/01-1593
CAPACITOR,FIXED,CER  USED ON SERIAL
3
NO 1828A00001 THROUGH 1908A99999
7
PADZZ
56289
196D686X9006KA1
CAPACITOR,FIXED,ELE  USED ON SERIAL
4
NO 1828A00001 THROUGH 1908A99999
8
PADZZ
02114
VK20020/4B
CHOKE,RADIO FREQUEN  USED ON SERIAL
3
NO 1828A00001 THROUGH 1908A99999
9
PADZZ
56289
196D686X9006KA1
CAPACITOR,FIXED,ELE  USED ON SERIAL
2
NO 1828A00001 THROUGH 1908A99999
10
PADZZ
81349
M39003/01-3003
CAPACITOR,FIXED,ELE  USED ON SERIAL
1
NO 1828A00001 THROUGH 1908A99999
11
PADZZ
96906
MS90539-15
COIL,ELECTRICAL  USED ON SERIAL NO
1
1828A00001 THROUGH 1908A99999
12
PADZZ
81349
M39003/01-2962
CAPACITOR,FIXED,ELE  USED ON SERIAL
1
NO 1828A00001 THROUGH 1908A99999
13
PADZZ
81349
RCR05G100JS
RESISTOR,FIXED,COMP  USE ON SERIAL
1
NO 1828A00001 THROUGH 1908A99999
14
PADZZ
81349
RCR05G510JS
RESISTOR,FIXED,COMP  USED ON SERIAL
4
NO 1828A00001 THROUGH 1908A99999
15
PADZZ
81349
CMR05C180JPDR
CAPACITOR,FIXED,MIC  USED ON SERIAL
9
NO 1828A00001 THROUGH 1908A99999
16
PADZZ
81349
RCR05G270JS
RESISTOR,FIXED,COMP  USED ON SERIAL
4
NO 1828A00001 THROUGH 1908A99999
17
PADZZ
81349
RCR07G202JS
RESISTOR,FIXED,COMP  USED ON SERIAL
5
NO 1828A00001 THROUGH 1908A99999
18
PADZZ
81349
RCR05G560JS
RESISTOR,FIXED,COMP  USED ON SERIAL
1
NO 1828A00001 THROUGH 1908A99999
19
PADZZ
81349
RCR05G300JS
RESISTOR,FIXED,COMP  USED ON SERIAL
1
NO 1828A00001 THROUGH 1908A99999
20
PADZZ
81349
RCR07G181JS
RESISTOR,FIXED,COMP  USED ON SERIAL
2
NO 1828A00001 THROUGH 1908A99999
21
PADZZ
16845
1000-409-15
TRANSISTOR  USED ON SERIAL NO
1
1828A00001 THROUGH 1908A99999
22
PADZZ
32997
3329WT22-102
RESISTOR,VARIABLE,N  USED ON SERIAL
1
NO 1828A00001 THROUGH 1908A99999
23
PADZZ
81349
RCR07G200JS
RESISTOR,FIXED,COMP  USED ON SERIAL
2
NO 1828A00001 THROUGH 1908A99999
5-1
