 TM 5-4930-233-24P
SECTION II
TM 4930-24P/2
(1)
(2)
(3)
(4)
(5)
(6)
ITEM
SMR
PART
NO
CODE
CAGEC
NUMBER
DESCRIPTION AND USABLE ON CODES(UOC)
QTY
GROUP 02 TRAILER ASSEMBLY
POWER CLUSTER
1
PAFZZ
96906
MS35842-11
.CLAMP,HOSE ................................ ...........................
1
2
PBFZZ
96906
MS521301A204R
.HOSE,NONMETALLIC ................................ ..............
1
3
XDFZZ
19207
8365426
.TUBE ASSEMBLY,METAL ................................ ........
1
4
PAFFO
19207
8357980
.CYLINDER ASSEMBLY,H ................................ .........
1
5
XDOZZ
06721
GN-3550
.BRACKET,BRAKE ................................ .....................
1
6
PAFZZ
19207
8365427
..COLLAR,AIR CHAMBER ................................ ..........
1
7
XDFFF
06721
N-30171
..HYDRAULIC UNIT,AIR CHAMBER .........................
1
8
XDFZZ
06721
02W12416
...NUT, HEX ................................ ...............................
3
9
XDFZZ
06721
35W52024
...WASHER, LOCK ................................ .....................
3
10
XDFZZ
06721
2-X-5729
...NUT ................................ ................................ .........
1
11
XDFZZ
06721
3-X-706
...BOLT ................................ ................................ .......
1
12
XDFZZ
06721
N-20166-D
...CLAMP, BAND ................................ ........................
1
13
XDFZZ
06721
N-15656-BA
...COVER ASSEMBLY ................................ ................
1
14
XDFZZ
06721
201096
...BODY ASSEMBLY ................................ ..................
1
15
PAFZZ
06721
N-20151
...DIAPHRAGM,CHAMBER,B ................................ .....
1
16
XDFZZ
06721
102583-Z
...ROD ASSEMBLY, PUSH ................................ .........
1
17
PAFZZ
06721
N-11728-N
...PACKING,PREFORMED ................................ .........
1
18
XDFZZ
06721
N-12977
...SPRING ................................ ................................ ..
1
END OF FIGURE
41-1
|
|
