 SECTION II
TM5-4930-223-24P
TM 4930-24P/2
(1)
(2)
(3)
(4)
(5)
(6)
ITEM
SMR
PART
NO
CODE
CAGEC
NUMBER
DESCRIPTION AND USABLE ON CODES(UOC)
QTY
GROUP 02 TRAILER ASSEMBLY
1
XCOFF 19099 13227E9539
.BRAKE ASSY, TRAILER ................................ ............
1
2
XDOZZ 96906 MS35746-1
..COUPLER,AIR BRAKE EMERGENCY, ....................
1
PAINTED RED ................................ ...........................
3
XDOZZ 96906 MS35746-1
..COUPLING HALF,QUICK SERVICE, .......................
1
PAINTED BLUE................................ ...........................
4
XDOZZ
98343
1509
..PACKING,PREFORMED ................................ ...........
2
5
PAOZZ
96906
MS39133-A-2-B
..ADAPTER ASSY,AIR ................................ ................
2
6
PAOZZ
19099
13227E9539-4
..HOSE ASSY,NONMETALL ................................ .......
2
7
XDOZZ
96906
MS53004-1
..VALVE, EMERGENCY ................................ ..............
1
8
XDOZZ
96906
HS51953-105
..NIPPLE,PIPE 3/4-14 NPT X 4 IN ..............................
1
9
XDOZZ
19099
13227E9535
..AIR CLEANER................................ ...........................
2
10
PAOZZ
06721
N-11728-BY
...PACKING,PREFORMED ................................ ..........
1
11
PAOZZ
06721
N-12971-B
...FILTER ELEMENT,FLUI ................................ ...........
1
12
XDOZZ
96906
MS51953-29
..NIPPLE,PIPE 1/4-18 NPT................................ .........
2
13
XDOZZ
19099
13227E9537
..VALVE, ASSY ................................ ...........................
1
14
XDFZZ
19099
13227E9536
..VALVE, ASSY ................................ ...........................
1
15
XDOZZ
96906
MS51967-2
..NUT, PLAIN HEX 1/4-20 UNC ................................ ..
4
16
XDOZZ
96906
MS51415-5
..WASHER,LOCK 1/4 IN ID ................................ .........
4
17
XDOZZ
96906
MS51412-3
..WASHER, FLAT 1/4 IN ID ................................ .........
8
18
PBOZZ
80204
B1821BHO25ClOON
..SCREW,CAP,HEXAGON H 1/4-20 UNC X...............
4
1 IN ................................ ................................ .............
19
XDOZZ
19099
13227E9538
..TANK, AIR................................ ................................ .
1
20
PAOZZ
96906
MS35782-5
...COCK,DRAIN ................................ ...........................
1
21
XDOZZ
96906
MS53007-2
..TAG, AIR BRAKE (EMERGENCY BRAKE) ..............
1
22
XDOZZ
96906
MS53007-1
..PLATE,IDENTIFICATIO (SERVICE ..........................
1
BRAKE)................................ ................................ .......
23
XDOZZ
81343
SAE130239
..ELBOW,STREET,3/8NPT ................................ .........
2
24
XDOZZ
19099
13227E9563-2
..CONNECTOR ................................ ...........................
2
25
XDOZZ
81343
SAE120202BA3/8NP
..ELBOW, MALE 3/8 NPT TO 3/8 TUBE.....................
4
T-3/8TUBE
26
MOOZZ 97403
13227E9539-10
..TUBING,AIR BRAKE MAKE FROM P/N ..................
5
3A13130, 16 FEET LONG. ................................ ..........
27
XDOZZ
96906
MS20600-B6W5
..RIVET ................................ ................................ .......
8
28
XDOZZ
96906
MS21333-67
..CLAMP,LOOP ................................ ...........................
8
29
XDOZZ
96906
MS21333-69
..CLAMP,LOOP ................................ ...........................
4
30
MOOZZ
97403
13227E9539-23
..TUBING, AIR BRAKE MAKE FROM P/N ..................
1
ASTM-A519, 1/4 IN OD, 62 INCHES LONG
31
XDOZZ
81343
SAE120102BA
..REDUCER,ADAPTER 1/4 -18 NPT TO 3/ ................
1
8 OPENING................................ ................................ .
32
XDOZZ
96906
MS14315-8X14
..REDUCER 3/4 NPT X 3/8 NPT................................ .
1
33
XDOZZ
19099
13227E9578
..FITTING ................................ ................................ ....
1
34
XDOZZ
81343
SAE040102
..FITTING 7/16-24 NPTF TO 1/4 TUBE, ....................
1
INVERTED FLARE ................................ ......................
35
XDOZZ
81343
SAE120202BA1/4NP
..ELBOW,MALE ................................ .........................
5
18T-3/8TUBE
END OF FIGURE
40-1
|
|
