GROUP 01 ENCLOSURE AND SKID ASSEMBLY (CONT) |
|
||
| ||||||||||
|
|
 SECTION II
TM5 4930-233-24P
TM 4930-24P/2
(1)
(2)
(3)
(4)
(5)
(6)
ITEM
SMR
PART
NO
CODE
CAGEC
NUMBER
DESCRIPTION AND USABLE ON CODES(UOC)
QTY
32 XDOZZ
96906
MS35842-10
....CLAMP, HOSE.. ................................ ............................ .2
33 XDOZZ
19099
13227E9409-4
....BARB, HOSE ... ................................ ............................ .2
34 MOOZZ
19099
13227E9541-7-23
....HOSE, AIR23.0 IN. LONG, MAKE ................................ .. 1
FROM P/N MIL-H-13444, TYPE III, 3/8IN ID
35
XDOZZ
97403
13227E9541-8
...HOSE ASSY, AIR60 IN. LONG ................................ ...... 1
36
XDOZZ
96906
MS35842-10
....CLAMP, HOSE .... ................................ .......................... 2
37
XDOZZ
19099
13227E9409-2
....BARB, HOSE ... ................................ ........................... ..2
38
MOOZZ
19099
13227E9541-8-60
....HOSE, AIR60 IN. LONG, MAKE ................................ ..... 1
FROM P/N MIL-H-13444, TYPE III, 1/4 IN. ID.. ................. ...
39
XDOZZ
96906
MS39230-3
...ELBOW, STREET, 90 DEG ................................. .......... .3
40
XDOZZ
19099
13227E9441
...BRACKET, MANIFOLD.... ................................ .............. .1
41
XDOZZ
19099
13227E9440
...MANIFOLD, AIR . ................................ ........................... .1
42
XDOZZ
19099
13227E9414-2
...VALVE, BALL .. ................................ .............................. .1
43
XDOZZ
96906
MS14304-2T1208
...BUSHING, REDUCER3/4 NPT TO 1/21 NPT ....................
44
XDOZZ
96906
MS39230-4
...ELBOW, STREET, 90 DEG1/2 NPT ..... .......................... 2
45
XDOZZ
96906
MS51816
...ADAPTER, STRAIGHT .................................... ............... 1
46
XDOZZ
96906
MS51813-6
...ELBOW ................................ ................................ .......... 1
47
XDOZZ
96906
MS14304-2T0806
...BUSHING, REDUCER1/2 NPT TO 3/8 NPT... ................. 1
48
XDOZZ
96906
MS39230-2
...ELBOW, PIPE . ................................ ............................ ...1
END OF FIGURE
37-2
|
|
