GROUP 01 ENCLOSURE AND SKID ASSEMBLY (CONT)

TM5-4930-233-24P

SECTION II

TM-4930-24P/2

(1)

(2)

(3)

(4)

(5)

(6)

ITEM

SMR

PART

CODE

CAGEC

NUMBER

DESCRIPTION AND USABLE ON CODES(UOC)

QTY

PAFZZ

53239

14319

. ..BEARING, PISTON, PIN ................................

XDFZZ

53239

37007

.... PIN, ROLL ................................ ....................

XDFZZ

53239

47945

... WRIST PIN LP ................................ ...............

PAFZZ

53239

48176

....PISTON, COMPRESSOR., ..............................

XDFZZ

53239

47946

.....RING, TOP COMPRESSIO HP .......................

XDFZZ

53269

47968

.....RING, BOTTOM COMPRES HP .....................

XDFZZ

53239

47947

.....RING, OIL CONTROL ................................ ....

XAFZZ

53239

47944

... PISTON, COMPRESSOR................................

XDFZZ

53239

47949

... WRIST PIN HP ................................ ...............

PAFZZ

53239

48175

....PISTON, VALVE ................................ ..............

XDFZZ

53239

47941

.....RING, TOP, COMPRESSIO LP ......................

XDFZZ

53239

47942

.....RING, BOTTOM COMPRES LP ......................

XDFZZ

53239

47943

.....RING, OIL CONTROL, LP ...............................

XAFZZ

53239

47948

.....PISTON HP ................................ ....................

END OF FIGURE

24-2
