GROUP 01 ENCLOSURE AND SKID ASSEMBLY |
|
||
| ||||||||||
|
|
 TM 5-4930-233-24P
SECTION II
TM 4930-24P/2
(1)
(2)
(3)
(4)
(5)
(6)
ITEM
SMR
PART
NO
CODE
CAGEC
NUMBER
DESCRIPTION AND USABLE ON CODES(UOC)
QTY
GROUP 01 ENCLOSURE AND SKID
ASSEMBLY
1
PAOFZ
96906
MS53013-1
..STARTER, ENGINE, ELEC ................................ ......
1
2
XDFZZ
19728
19X3439
...NUT, PLAIN, HEX ................................ ....................
2
3
XDFZZ
96906
MS35338-48
...WASHER, LOCK ................................ .....................
3
4
XDFZZ
96906
MS51969-3
...NUT, PLAIN, HEXAGON ................................ .........
1
5
XDFZZ
68505
12X201
...WASHER, LOCK ................................ .....................
1
6
XDFZZ
19728
MES85
...CONNECTOR, SWITCH ................................ .........
1
7
XDFZZ
19728
MES61
...PLUG, MACHINE ................................ ....................
1
8
XDFZZ
19728
MFI63
..GASKET ................................ ................................ ...
1
9
XDFZZ
19728
8X1681
..NUT, PLAIN HEX ................................ ......................
1
10
XDFZZ
19207
7748641
...SCREW................................ ................................ ....
4
11
XDFZZ
68505
SAT4106UT
...RELAY-SOLENOID, ENGI ................................ .......
1
12
XDFZZ
19728
8X3147
...SCREW, CAP ................................ ..........................
6
13
XDFZZ
19728
MFY34S
...PLUG, NEOPRENE ................................ .................
6
14
XDFZZ
19728
PS1390B
...HOUSING ................................ ................................
1
15
XDFZZ
19728
MYF36
...BEARING ................................ ................................
1
16
XDFZZ
19728
X3817
...PLUG, PIPE ................................ ............................
2
17
XDFZZ
19728
MBS150
...WICK ................................ ................................ .......
2
18
XDFZZ
19728
XA775AQ
...PACKING, PREFORMED ................................ ........
1
19
XDFZZ
19728
MFY35
...BEARING, WASHER................................ ................
1
20
XDFZZ
19728
8X3656
...SCREW, MACHINE ................................ .................
2
21
XDFZZ
09728
MFY39
...WASHER, FLAT ................................ ......................
2
22
XDFZZ
19728
XA44AP
...PACKING, PREFORMED ................................ ........
2
23
XDFZZ
19728
X3190
...SCREW W/ WASHER ................................ .............
2
24
XDFZZ
19728
MFY37BS
...COVER, YOKE ................................ ........................
1
25
XDFZZ
19728
MFY38
...GASKET ................................ ................................ ..
1
26
XDFZZ
19728
MES66A
...PIN, STRAIGHT ................................ ......................
1
27
XDFZZ
19728
PDBA
...DRIVE, ENGINE ................................ ......................
1
28
XDFZZ
19728
MFY2042
...FORK, SHIFTER ................................ .....................
1
29
XDFZZ
19728
8X3360
. .SCREW, CAP, HEX ................................ ................
7
30
XDFZZ
19728
MFY2030B
...HOUSING ASSEMBLY ................................ ............
1
31
XDFZZ
19728
XA1026
..PACKING ASSEMBLY ................................ .............
1
32
XDFZZ
19728
ML21A
...BEARING ................................ ................................
1
33
XDFZZ
19728
XA774Z
...PACKING, PREFORMED ................................ ........
1
34
XDFZZ
19728
MU54
...WASHER, FLAT ................................ ......................
1
35
XDFZZ
19728
MES2105A
...ARMATURE, MOTOR ................................ .............
1
36
XDFZZ
19728
MU54B
...WASHER, FLAT................................ .......................
1
37
XDFZZ
19728
ML129
...WASHER, FLAT ................................ ......................
2
38
XDFZZ
19728
19X3437
...NUT, PLAIN, HEX ................................ ....................
1
39
XDFZZ
19728
MES78A
...WASHER, FLAT ................................ ......................
1
40
XDFZZ
19728
MES93
...WASHER, INSULATING ................................ ........
1
41
XDFZZ
19728
MES99
...WASHER, FLAT ................................ ......................
1
42
XDFZZ
19728
MES94
...WASHER, INSULATION ................................ .........
1
43
XDFZZ
19728
8X3445
...SCREW................................ ................................ ....
7
44
XDFFF
19728
MFY1002JS
...HEAD ASSY, STARTER ................................ ..........
1
45
XDFZZ
19728
MES72
....BUSHING, INSU ................................ .....................
1
46
XDFZZ
19728
MES71
....WASHER, INSULATING ................................ ........
1
47
XDFZZ
19728
MES95
....GASKET ................................ ................................ .
1
17-1
|
|
