GROUP 01 ENCLOSURE AND SKID ASSEMBLY |
|
||
| ||||||||||
|
|
 TM 5-4930-233-24P
SECTION II
TM 4930-24P/2
(1)
(2)
(3)
(4)
(5)
(6)
ITEM
SMR
PART
NO
CODE
CAGEC
NUMBER
DESCRIPTION AND USABLE ON CODES(UOC)
QTY
GROUP 01 ENCLOSURE AND SKID
ASSEMBLY
1
XDOOO
19099
13227E9450
..CABINET, REEL ASSY ................................ ............
1
2
XDOZZ
96906
MS90725-60
...SCREW, CAP, HEXAGON H GRADE 5, ................
20
.375-16 UNC X 1.0 IN................................ ..................
3
XDOZZ
96906
M51415-7
...WASHER, LOCK ................................ .....................
20
4
XDOZZ
96906
MS51412-7
...WASHER, FLAT ................................ ......................
20
5
XDOZZ
96906
MS35649-202
...NUT, PLAIN, HEXAGON ................................ .........
1
6
XDOZZ
96906
MS51849-76
...SCREW, MACHINE ................................ .................
1
7
XDOZZ
96906
MS51415-3
...WASHER, LOCK ................................ .....................
1
8
XDOZZ
96906
MS21334-28
...CLAMP, LOOP ................................ ........................
1
9
XDOZZ
05693
4345-6-8
...RIVET, PULL 0.187 DIA, ALUMINUM.. ....................
1
10
XDOZZ
81349
MIL-P-17802
... CHAIN AND PADLOCK ................................ ..........
1
11
XDOZZ
19099
13227E9463
... LOCKBAR ................................ ..............................
1
12
XDOZZ
19099
13227E9459
...TRAY COMPARTMENT ................................ ..........
1
13
XDOZZ
19099
13227E9419
...DRAWER, TOOL, TOP ................................ ...........
1
14
XDOZZ
96906
MS90725-1
...SCREW, CAP, HEXAGON H ................................ ...
4
15
XDOZZ
96906
MS51415-5
...WASHER, LOCK ................................ .....................
4
16
XDOZZ
19099
13227E9461
... DRAWER STOP ................................ .....................
2
17
XDOZZ
19099
13227E9421
...DRAWER, TOOL, BOTTOM ................................ ....
1
18
PAOZZ
96906
MS9245-47
...PIN, COTTER ................................ ..........................
1
19
XDOZZ
19099
13227E9454
...LEVER, MANUAL CONTRO ................................ ....
1
20
PAOZZ
93061
XV-500P-4
...VALVE, BALL 0.25-18 NPTF ................................ ..
1
21
XDOZZ
96906
MS35489-156
...GROMMET ................................ ..............................
1
22
XDOZZ
96906
MS20600-AD6W5
...RIVET, PULL ................................ ...........................
10
23
XDOZZ
19099
13227E9460-4
...PLATE IDENTIFICATIO ................................ ..........
1
24
XDOZZ
97403
13227E9460-3
...PLATE, IDENTIFICATIO ................................ .........
2
25
XDOZZ
19099
13227E9460-2
...PLATE, IDENTIFICATIO ................................ .........
1
26
XDOZZ
19099
13227E9460-1
...PLATE, IDENTIFICATIO ................................ .........
1
27
XBFFF
19099
13227E9418
...CABINET, SMALL PARTS................................ ........
1
END OF FIGURE
9-1
|
|
