 SECTION II
TM 5-2815-231-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM SMR
PART
NO CODE FSCM
NUMBER
DESCRIPTION AND USABLE ON CODES (UOC)
QTY
87
PAFZZ
33287
J8165-2
GAGE, DIAL, VALVE SEA ................................ .......
88
PAFZZ
33287
J6390-02
VALVE SEAT GRINDER SEAT GRINDER..............
89
PAOZZ
33287
J7924-1
WHEEL, GRINDING 15 DEGREE ............................
90
PAOZZ
33287
J7924-2
WHEEL, GRINDING 31 DEGREE ............................
91
PAOZZ
33287
J7924-3
WHEEL, GRINDING 60 DEGREE ............................
92
PAOZZ
33287
J7659-1
PILOT, VALVE SEAT RE ................................ .........
93
PAHZZ
33287
J9784
INSTALLER, OIL SEAL SLEEVE ............................
94
PAOZZ
33287
J23775-01
WRENCH, TORQUE 100 - 600 FT-LBS..................
95
PAFZZ
72582
5199913
INSTALLER, EXHAUST V VALVE SEAL.................
96
PACZZ
33287
J24406
WRENCH, RATCHET 5 - 100 FT-LBS ....................
97
PAFZZ
33287
J7455
COMPRESSOR, VALVE SP SPRING .....................
98
PAOZZ
33287
J7455-2
PIN, VALVE SPRING ................................ ...............
99
PAOZZ
33287
J7455-3
HANDLE, VALVE SPRING................................ .......
100
PAOZZ
33287
J7455-4
ADAPTER, VALVE SPRING ................................ ....
101
PAOZZ
33287
J7455-7
POST, VALVE COMPRESS................................ .....
102
PAOZZ
33287
J7455-9
BRACKET, SPRING COMP ................................ .....
103
PAFZZ
33287
J-6569-A
REMOVER, VALVE GUIDE................................ ......
104
PAFZZ
33287
J5437
BRUSH, WIRE, VALVE CL GUIDE ..........................
105
PAFZZ
33287
J23479-D
REMOVER, INSERT, VALVE SEAT.......................
106
PAOZZ
33287
J23479-10
COLLET ................................ ................................ ...
107
PAOZH
33287
J-23479-35
PULLER ASSEMBLY ................................ ...............
108
PAOZZ
33287
J-23479-21
BODY, REMOVER, INSERT ................................ ....
109
PAOZZ
33287
J23479-3
CAM AND HANDLE, INSE HANDLE .......................
110
PAOZZ
33287
J23479-4
NUT, REMOVER, INSERT ................................ .......
111
PAOZZ
33287
J23479-5
SPRING, HELICAL, COMP ................................ ......
112
PAOZZ
33287
J23479-6
BOLT, EYE ................................ ..............................
113
PAFZZ
33287
J6568
REPLACING TOOL, ENGI VALVE SEAT.................
114
PAFZZ
33287
J7040
GRINDER SET, VALVE SEAT ................................ .
115
PAFZZ
33287
J24420-A
PULLER KIT, UNIVERSAL................................ .......
116
PAHZZ
33287
J4870
PULLER, WATER PUMP DRIVE GEAR..................
117
PAHZZ
33287
J5347-B
GAGE, CYLINDER BORE ................................ .......
118
PAHZZ
33287
J5580-1
GAGE, RING DIAMETER CYLINDER BORE
4.2500 ................................ ................................ .....
119 PAHZO 33287 J21716-01
REMOVAL TOOL, LINER................................ .........
LINER ................................ ................................ ......
120 PAHZZ 33287 J21793-B
CLAMP, HOLD DOWN CYL LINER HOLD
DOWN ................................ ................................ ....
121
PAHZZ
33287
J22273-01
GAGE, DEPTH CYLINDER LINER..........................
122
PAOZZ
33287
J7333-02
INDICATOR, DIAL ................................ ....................
123
PAOZZ
33287
J4209-25
BLOCK, ASSEMBLY HOLDER ...............................
124
PAFZZ
33287
J21520
INSTALLER, VALVE GUI GUIDE ............................
125
PAOZZ
32287
J24619
ALIGNMENT TOOL................................ ..................
END OF FIGURE
42-3/(42-4 blank)
|
|
