 SECTION II
TM 5-2815-231-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM SMR
PART
NO CODE FSCM
NUMBER
DESCRIPTION AND USABLE ON CODES (UOC)
QTY
GROUP 01
ENGINE
THROTTLE CONTROLS
1
PACZZ
96906
MS90728-62
SCREW,CAP,HEXAGON H ................................ .....
1
2
PACZZ
72582
103321
WASHER,LOCK................................ .......................
1
3
PACZZ
72582
5134051
BOLT,ENGINE ................................ .........................
1
4
PACZZ
72582
123221
NUT,PLAIN,HEXAGON ................................ ............
2
5
XDCZZ
72582
5145166
BRACKET ................................ ................................
1
6
XDCZZ
72582
5118896
SPACER SLEEVE................................ ....................
1
7
PACZZ
96906
MS35338-44
WASHER,LOCK................................ .......................
2
8
PACZZ
96906
MS90728-7
SCREW,CAP,HEXAGON H ................................ .....
1
9
XDCZZ
72582
5514041
SPRING ................................ ................................ ...
1
10
PACZZ
72582
5186749
NUT,PLAIN,HEXAGON ................................ ............
1
11
XDCZZ
72582
123880
LEVER ................................ ................................ .....
1
12
XDCZZ
72582
5171045
BOLT,MACHINE ................................ ......................
1
END OF FIGURE
41-1
|
|
