 SECTION II
TM 5-2815-231-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM SMR
PART
NO CODE FSCM
NUMBER
DESCRIPTION AND USABLE ON CODES (UOC)
QTY
GROUP 01
ENGINE
OIL PAN AND DIPSTICK
1
PAHZZ
96906
MS90727-58
SCREW,CAP,HEXAGON H X 3/4 IN........................
1
2
PAHZZ
96906
MS35338-8
WASHER,LOCK................................ .......................
4
3
XDHZZ
72582
5153473
CLIP, DIPSTICK ................................ .......................
1
4
XDHZZ
72582
8921988
GAGE ROD,LIQUID LEV ................................ .........
1
5
XDHZZ
72582
5126358
BRACKET ................................ ................................
1
6
PAHZZ
72582
117049
NUT,PLAIN,HEXAGON ................................ ............
1
7
XDHZZ
72582
5177863
ADAPTER ................................ ................................
1
8
XDHZZ
72582
5151430
ADAPTER,STRAIGHT,PI ................................ .........
1
9
PAHZZ
96906
MS27183-15
WASHER,FLAT................................ ........................
4
10
PAHZZ
96906
MS90728-61
SCREW,CAP,HEXAGON H X 1-1/8 IN.....................
2
11
PAHZZ
96906
MS90728-62
SCREW,CAP,HEXAGON H X 1-1/4 IN.....................
2
12
PAHZZ
96906
MS90725-75
SCREW,CAP,HEXAGON H -1/4 IN ..........................
2
13
PAHZZ
72582
187491
SCREW,CAP,HEXAGON H X 5-1/2 IN.....................
2
14
PAHZZ
72582
5144590
GASKET ................................ ................................ ..
1
15
PAHZZ
72582
5152148
WASHER,FLAT 9/16 IN, FLAT COPPER................
1
16
PAHZZ
96906
MS18154-60
SCREW,CAP,HEXAGON H X 1 IN...........................
18
17
XDHZZ
72582
5143994
PAN OIL LOWER................................ .....................
1
18
PAHZZ
72582
5148480
SCREW,CAP,HEXAGON H /8 IN............................
14
19
XDHZZ
72582
5125624
COVER ................................ ................................ ....
1
20
PCHZZ
72582
5124796
GASKET ................................ ................................ ..
1
21
PAHZZ
81349
MILB857
BOLT 3/8 IN. - 16 X 6 IN ................................ ..........
4
22
PAHZZ
72582
9419283
BOLT X 1-1/2 IN................................ .......................
28
23
XDHZZ
72582
5196822
PAN UPPER OIL................................ ......................
1
24
PCHZZ
72582
5109915
GASKET ................................ ................................ ..
1
END OF FIGURE
32-1
|
|
