 SECTION II
TM 5-2815-231-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM SMR
PART
NO CODE FSCM
NUMBER
DESCRIPTION AND USABLE ON CODES (UOC)
QTY
GROUP 01 ENGINE
1
XDHZZ
72582
5150087
NUT,PLAIN,HEXAGON HEX................................ ...
4
2
XDHZZ
72582
5177769
WASHER,LOCK IN INTERNAL TOOTH..................
4
3
XDHZZ
72582
5122259
PULLEY,GROOVE................................ ...................
1
4
XDHZZ
72582
5116485
SPACER,RING................................ .........................
2
5
XDHZZ
72582
5106223
SEAL,PLAIN ENCASED................................ ...........
1
6
XDHZZ
72582
9414268
BOLT,MACHINE X 1- IN FRONT ..12 ...................
6
PT HD ................................ ................................ ......
7
XDHZZ
72582
103321
WASHER,LOCK................................ .......................
6
8
XDHZZ
72582
5117984
BEARING,SLEEVE BUSHING ................................
2
9
PCHZZ
72582
5117243
GASKET ................................ ................................ ..
1
10
PAHZZ
72582
127559
KEY,WOODRUFF ................................ ....................
1
11
XDHZZ
72582
5117850
CAMSHAFT,ENGINE LEFT BANK ..........................
1
12
PAFZZ
72582
5117649
SETSCREW................................ .............................
10
13
PAHZZ
72582
5196026
BEARING HALF SET,SL................................ ..........
10
14
PAHZZ
72582
5115572
RING,RETAINING ................................ ....................
20
15
PAHZZ
72582
5153914
KEY,WOODRUFF ................................ ....................
2
16
PAHZZ
72582
5111424
BEARING,WASHER,THRU................................ ......
4
17
XDFZZ
72582
5111422
BEARING,SLEEVE BUSHING ................................
2
18
XDHZZ
72582
186622
BOLT 3/8 IN. - 16 X 1 IN................................ .....
6
19
PAHZZ
72582
5117133
GEAR,HELICAL LEFT BANK,REAR .......................
1
20
PAHZZ
72582
5172734
PLATE,RETAINING,SHA ................................ .........
2
21
XDFZZ
72582
186627
SCREW,CAP,HEXAGON H X 1 IN..........................
8
22
PAHZH
72582
5199384
GEAR ASSY,HELICAL IDLER................................ .
1
23
PAHZZ
72582
5126839
GEAR,SPUR FRONT (66 TEETH) ..........................
1
24
XDHZZ
72582
5117849
CAMSHAFT,ENGINE RIGHT BANK........................
1
25
PAHZZ
72582
5117134
GEAR,HELICAL RIGHT BANK,REAR .....................
1
END OF FIGURE
29-1
|
|
