 SECTION II
TM 5-2815-231-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM SMR
PART
NO CODE FSCM
NUMBER
DESCRIPTION AND USABLE ON CODES (UOC)
QTY
GROUP 01 ENGINE
1
PCFZZ
72582
5144875
GASKET ................................ ................................ ..
1
2
PAFZZ
72582
103321
WASHER,LOCK................................ .......................
16
3
XDFZZ
72582
186679
BOLT 3/8 IN. - 16 X 1 IN................................ .....
1
4
PAFZZ
96906
MS18154-60
SCREW,CAP,HEXAGON H ................................ .....
2
5
PAFZZ
72582
5121466
BOLT,SPECIA................................ ..........................
7
6
PAFZZ
72582
103323
WASHER,LOCK................................ .......................
6
7
PAFZZ
96906
MS90728-120
SCREW,CAP,HEXAGON H ................................ .....
6
8
PAFZZ
72582
8925602
BOLT,SELF-LOCKING IN 16 X 1 IN........................
6
9
XDFZZ
72582
5120753
PLATE,RETAINING,SHA SCUFF............................
1
10
XDFZZ
72582
9411631
BOLT,SELF-LOCKING 2-3/4 IN ..............................
1
11
XDFZZ
72582
5174748
FLYWHEEL ASSY ................................ ...................
1
12
XDFZZ
72582
5184773
GEAR,SPUR ................................ ............................
1
13
XDFZZ
72582
5146646
PLUG 1 IN. PIPE ................................ ................
1
14
XDFZZ
72582
5111798
PLUG,PIPE ................................ ..............................
1
15
XDFZZ
72582
5132454
HOUSING ................................ ................................
1
END OF FIGURE
28-1
|
|
