SECTION II
TM 5-2815-231-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM SMR
PART
NO  CODE FSCM
NUMBER
DESCRIPTION AND USABLE ON CODES (UOC)
QTY
GROUP 01 ENGINE
FIG. 27 VALVE ROCKER ARM COVER
1 PAOZZ 72582 5104015
BOLT PART OF KIT P/N 5149512 ...........................
8
2 PAOZZ 72582 5104514
WASHER,FLAT PART OF KIT P/N 5149512............
8
3 XDOZZ 72582 5104515
MOUNT,RESILIENT PART OF KIT P/N ...................
8
5149512................................ ................................ .
4 XDOZZ
72582
5103744
COVER,ENGINE POPPET LH ................................
1
5 XDOZZ
72582
5103738
COVER, ROCKER ARM RH................................ ....
1
6 PCOZZ
72582
5104019
GASKET PART OF KIT P/N 5149512 ......................
2
PCOZZ
72582
5149512
PARTS KIT, ROCKER AR ONE BANK....................
1
BOLT
( 8)
27-1
GASKET
( 2)
27-6
MOUNT, RESILIENT
( 8)
27-3
WASHER, FLAT
( 8)
27-2
END OF FIGURE
27-1
