SECTION II
TM 5-2815-231-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM SMR
PART
NO  CODE FSCM
NUMBER
DESCRIPTION AND USABLE ON CODES (UOC)
QTY
GROUP 01 ENGINE
FIG. 22 INSTRUMENT PANEL
1
XDOZZ
72582
8920568
INSTRMNT PANEL ASSY ................................ ........
1
2
XDOZZ
72582
6474061
AMMETER (60 AMP.) ................................ ..............
1
3
XDOZZ
72582
6463500
GAGE,PRESSURE,DIAL................................ ..........
1
4
XDOZZ
72582
5658119
TACHOMETER ................................ ........................
1
5
XDOZZ
72582
6463913
GAGE (80#) ................................ .............................
1
6
XDOZZ
72582
6490964
GAGE(30INCAPILLARY................................ ...........
1
7
PAOZZ
96906
MS24523-31
SWITCH,TOGGLE 3 POS MOM ON/OFF/ON. .......
1
8
PAOZZ
96906
MS51922-17
NUT,SELF-LOCKING,HE V4-20UNC-2B.................
4
END OF FIGURE
22-1
