 SECTION II
TM 5-2815-231-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM SMR
PART
NO CODE FSCM
NUMBER
DESCRIPTION AND USABLE ON CODES (UOC)
QTY
GROUP 01 ENGINE
1
XDOZZ
72582
5117713
TANK ................................ ................................ .......
1
2
PCOZZ
72582
5118061
GASKET ................................ ................................ ..
1
3
PAOZZ
24617
850795
CAP,FILLER OPENING ................................ ...........
1
4
XDOZZ
72582
5118060
FILLER NECK ................................ ..........................
1
5
PCOZZ
72582
5117406
GASKET ................................ ................................ ..
2
6
XDOZZ
96906
MS51879-5
ELBOW,PIPE TO TUBE................................ ...........
1
7
XDOZZ
72582
5117442
COVER (INLET) ................................ .......................
1
8
PAOZZ
96906
MS35338-8
WASHER,LOCK................................ .......................
4
9
PAOZZ
96906
MS90728-32
BOLT,MACHINE X 3/4 IN................................ ........
28
10
XDOZZ
72582
5158825
TUBE ASSEMBLY,METAL 4 IN)..... ....................
1
11
PAOZZ
96906
MS18154-60
SCREW,CAP,HEXAGON H 1 IN.............................
4
12
PAOZZ
72582
013320
WASHER,LOCK................................ .......................
4
13
XDOZZ
72582
5148336
COVER ................................ ................................ ....
1
14
PCOZZ
72582
5122975
GASKET ................................ ................................ ..
1
15
PAOZZ
72582
5117186
PLUG,EXPANSION................................ ..................
2
16
PAOZZ
96906
MS35338-50
WASHER,LOCK................................ .......................
4
17
PAOZZ
72582
271570
BOLT 5/8 IN. - 11 X 4................................ .............
2
18
PAOZZ
96906
MS35338-10
WASHER,LOCK.......................................................
1
19
PAOZZ
72582
187152
BOLT ................................ ................................ .......
1
20
PAOZZ
72582
271563
BOLT ................................ ................................ .......
1
21
XDOZZ
72582
5140559
BRACKET,LOWER ................................ ..................
1
22
XDOZZ
72582
5117440
COVER (BLANK) ................................ .....................
1
23
PAOZZ
72582
454992
BOLT ................................ ................................ .......
2
24
XDOZZ
72582
5131752
BRACKET,UPPER ................................ ...................
1
25
PAOZZ
72582
5125720
STUD,PLAIN ................................ ............................
2
26
PAOZZ
72582
103328
NUT ................................ ................................ .........
2
END OF FIGURE
20-1
|
|
