 SECTION II
TM 5-2815-231-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM SMR
PART
NO CODE FSCM
NUMBER
DESCRIPTION AND USABLE ON CODES (UOC)
QTY
GROUP 01 ENGINE
PAOOZ
72582
5149323
PUMP, COOLING SYSTEM ASSY ..........................
1
1
PAOZZ
72582
5145089
HOUSING, LIQUID PUMP................................ ........
1
2
PAOZZ
96906
MS35338-47
WASHER, LOCK................................ ......................
3
3
PAOZZ
72582
190909
BOLT 7/16 IN. - 14 X 5 IN................................ ........
1
4
PCOZZ
72582
5117976
GASKET PART OF KIT P/N 5198576 ......................
1
5
XDOZZ
72582
5117961
COVER ................................ ................................ ....
1
6
PAOZZ
72582
5131685
BOLT 3/4 IN ................................ ............................
4
7
PAOZZ
72582
187425
SCREW, CAP, HEXAGON H X 5 IN........................
1
8
PAOZZ
72582
5117972
NUT, SELF-LOCKING, HE PART OF KIT P/N .........
1
5198576................................ ................................ ...
9 PAOZZ 72582 120395
WASHER, FLAT 7/16 IN ................................ .........
1
10 XDOZZ 72582 5131600
IMPELLER ASSY PART OF KIT P/N .......................
1
5198576................................ ................................ ...
11 PAOZZ 72582 8924297
SEAL, WATERPUMP PART OF KIT P/N .................
1
5198576................................ ................................ ...
12 PAOZZ 72582 5117983
SEAL, PLAIN ENCASED PART OF KIT P/N ............
1
5198576................................ ................................ ...
13 XDOZZ 72582 5123150
SHAFT, SHOULDERED PART OF KIT P/N .............
1
5198576................................ ................................ ...
14 XDOZZ 72582 2954945
BEARING, BALL, ANNULA PART OF KIT P/N.........
4
5198576................................ ................................ ...
15 XDOZZ 72582 908270
BEARING, BALL, ANNULA PART OF KIT P/N.........
1
5198576................................ ................................ ...
16
XDOZZ
72582
274746
RING, LOCK PART OF KIT P/N 5198576 ................
1
17
XDOZZ
72582
5146254
GEAR, HELICAL ................................ ......................
1
18
XDOZZ
72582
5103544
RING, SEAL PART OF KIT P/N 5198576.................
1
19
PAOZZ
96906
MS90725-89
SCREW, CAP, HEXAGON H X 1-1/2 IN..................
1
20
PAOZZ
96906
MS27183-16
WASHER, FLAT................................ .......................
1
21
PAOZZ
72582
5115214
PLUG, PIPE ................................ .............................
1
PAOZZ
72582
5198576
REPAIR KIT, PUMPING FRESH WATER PUMP ....
1
BEARING, BALL, ANNULA
( 4)
15-14
BEARING, BALL, ANNULA
( 1)
15-15
GASKET
( 1)
15-4
IMPELLER ASSY
( 1)
15-10
NUT, SELF-LOCKING, HE
( 1)
15-8
RING, SEAL
( 1)
15-18
RING, LOCK
( 1)
15-16
SEAL, PLAIN ENCASED
( 1)
15-12
SEAL, WATERPUMP
( 1)
15-11
SHAFT, SHOULDERED
( 1)
15-13
END OF FIGURE
15-1
|
|
