 SECTION II
TM 5-2815-231-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM SMR
PART
NO CODE FSCM
NUMBER
DESCRIPTION AND USABLE ON CODES (UOC)
QTY
GROUP 01 ENGINE
1
PAFZZ
72582
186624
BOLT, MACHINE ................................ .....................
2
2
PAFZZ
96906
MS27183-14
WASHER, FLAT................................ .......................
5
3
PAFZZ
72582
454906
SCREW, CAP, HEXAGON H ................................ ...
3
4
PAFZZ
96906
MS35338-45
WASHER, LOCK................................ ......................
4
5
XDFZZ
72582
5117057
ADAPTER ASSY REAR ................................ ...........
1
6
PAFZZ
24617
180127
SCREW, CAP, HEXAGON H ................................ ...
5
7
PAFZZ
72582
5126280
SHIM ................................ ................................ ........
3
8
PAFZZ
72582
5127797
PLUG, PIPE ................................ .............................
1
9
PCFZZ
72582
5117535
GASKET ................................ ................................ ..
2
10
PCFZZ
15434
60598
WASHER, FLAT................................ .......................
1
11
PAFZZ
72582
5177778
SPRING, HELICAL, COMP ................................ ......
1
12
XDFZZ
72582
5177777
VALVE, OIL PRESSURE................................ ..........
1
13
XDFZZ
72582
5126257
ADAPTER ASSY REAR ................................ ...........
1
14
XDFZZ
72582
9139809
CLAMP, HOSE................................ .........................
1
15
PAFZZ
72582
5147744
HOSE, NONMETALLIC 4-1/2 IN L...........................
1
16
XDFZZ
72582
5188036
CLAMP 9/16 - 3 1/2 IN ................................ ............
2
17
PAFZZ
72582
5122422
ELBOW, FLANGE TO HOS ................................ .....
1
18
PAFZZ
96906
MS90728-61
SCREW, CAP, HEXAGON H ................................ ...
4
19
PAFZZ
96906
MS35338-8
WASHER, LOCK................................ ......................
9
20
PCFZZ
72582
5117317
GASKET ................................ ................................ ..
1
21
PAFZZ
72582
138244
BOLT, HEX HD 3/8 IN. - 16 ................................ .....
1
22
PCFZZ
72582
5117280
GASKET ................................ ................................ ..
1
23
PAFZZ
72582
5142549
PLUG, PIPE ................................ .............................
2
24
PCFZZ
72582
5117404
GASKET ................................ ................................ ..
3
25
XDFZZ
72582
8539503
CORE ASSEMBLY, OIL C COVER PLATES............
1
26
PCFZZ
72582
5124085
GASKET ................................ ................................ ..
1
27
XDFZZ
72582
5117553
COVER, OIL COOLER................................ .............
1
28
PAFZZ
72582
186274
BOLT5/16 IN. - 18 X 5 1/4 IN................................ ....
9
29
PAFZZ
72582
455971
BOLT5/16 IN. - 18 X 5 1/2 IN................................ ....
3
30
PAFZZ
72582
8924140
COCK, DRAIN................................ ..........................
1
31
PAFZZ
96906
MS90728-34
BOLT, MACHINE X 1 IN................................ ...........
2
32
PAFZZ
96906
MS90728-51
BOLT, MACHINE X 4 3/4 IN ................................ .....
11
33
XDFZZ
72582
8547554
CORE ASSY 12 PLS R ................................ ............
1
34
XDFZZ
72582
5116863
HOUSING ................................ ................................
1
35
XDFZZ
72582
5102098
SEAL................................ ................................ ........
1
36
PAFZZ
72582
5143999
CLAMP, HOSE................................ .........................
1
37
PAFZZ
96906
MS18154-60
SCREW, CAP, HEXAGON H 1 IN...........................
4
38
PAFZZ
72582
8923313
PLUG, PIPE ................................ .............................
1
39
PAFZZ
72582
5129834
ELBOW, OIL COOLER ................................ ............
1
40
PCFZZ
72582
5117254
GASKET ................................ ................................ ..
1
END OF FIGURE
14-1
|
|
