 SECTION II
TM 5-2815-231-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM SMR
PART
NO CODE FSCM
NUMBER
DESCRIPTION AND USABLE ON CODES (UOC)
QTY
GROUP 01 ENGINE
1
PAOZZ
96152
A82-1
PIN, COTTER ................................ ..........................
2
2
PAOZZ
96906
MS35671-24
PIN, GROOVED, HEADLES................................ .....
4
3
PAOZZ
72582
5150483
SPACER, SLEEVE................................ ...................
2
4
XDOZZ
72582
5101397
LEVER CONTROL INJEC ................................ ........
12
5
XDOZZ
72582
5149254
TUBE ASSY R BANK ................................ ...............
1
6
XDOZZ
72582
5130509
BRACKET, EYE, ROTATIN ................................ ......
2
7
PAOZZ
96906
MS35338-27
BOLT 1/4 IN. -20 X 5/8 IN................................ .........
8
8
PAOZZ
96906
MS35338-46
WASHER, LOCK................................ ......................
8
9
PAOZZ
72582
5150259
PIN, STRAIGHT, HEADED................................ .......
2
10
PAOZZ
72582
5101258
SPRING ................................ ................................ ...
2
11
PAOZZ
72582
5101295
SPRING, HELICAL, TORS ................................ .......
10
12
PAOZZ
72582
120613
NUT, HEX 1/4 IN. -28 ................................ ...............
12
13
PAOZZ
72582
5101392
SCREW X .90 IN................................ ......................
12
14
XDOZZ
72582
5149253
TUBE ASSY LEFT BANK................................ .........
1
15
PAOZZ
72582
5150258
PIN ................................ ................................ ...........
2
16
PAOZZ
72582
5124142
SPRING ................................ ................................ ...
2
17
XDOZZ
72582
5150263
LEVER, REMOTE CONTRO ................................ ....
2
18
XDOZZ
72582
5117942
LINK, LONG ................................ .............................
1
19
XDOZZ
72582
5117191
LINK (S) (L) BANK ................................ ...................
1
20
PAOZZ
72582
5147345
PIN 15/16 IN................................ .............................
2
END OF FIGURE
12-1
|
|
