 SECTION II
TM 5-2815-231-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM SMR
PART
NO CODE FSCM
NUMBER
DESCRIPTION AND USABLE ON CODES (UOC)
QTY
GROUP 01 ENGINE
PAOOF
72582
5228760
NOZZLE, FUEL INJECTI N60 ................................ .
1
1
PAOZZ
72582
5228588
ADAPTER, STRAIGHT, TU ................................ ......
1
2
PAOZZ
79150
19108
SPACER, RING................................ ........................
2
3
PAOZZ
79150
19108
SPACER, RING................................ ........................
1
4
PAOZZ
96906
MS90728-66
SCREW, CAP, HEXAGON H ................................ ...
1
5
PAOZZ
72582
5150250
WASHER, CONVEX ................................ ................
1
6
PAOZZ
72582
5121259
CLAMP, FUEL INJECTOR ................................ .......
1
7
XBOZZ
72582
5228779
TAG NUMBER N60 ................................ .................
1
8
PAOZZ
72582
5228583
BODY ASSEMBLY, FUEL ................................ ........
1
9
XBOZZ
72582
5226416
PIN, STRAIGHT, HEADLE HEADLESS...................
1
10
XBOZZ
72582
5226400
GEAR, SPUR ................................ ...........................
1
11
XDOZZ
72582
5228586
SPACER, SLEEVE................................ ...................
1
12
XBOZZ
72582
5228694
VALVE, CHECK ................................ .......................
1
13
PAOZZ
72582
5228596
SPRING, HELICAL, COMP ................................ ......
1
14
XBOZZ
72582
5228594
SEAT, HELICAL COMPRE................................ .......
1
15
PAOZZ
72582
5228109
SPACER, SLEEVE................................ ...................
1
16
PAOZZ
72582
5228601
NUT, INJECTOR, VALVE................................ .........
1
17
PAOZZ
72582
5229167
PACKING, PREFORMED................................ .........
1
18
PAOZZ
72582
5229026
SPRAY TIP, NOZZLE, FU ................................ ........
1
19
PAOZZ
72582
5228766
SEAT, HELICAL COMPRE................................ .......
1
20
PAOZZ
71934
5228696
GAGE, VALVE INJECTOR................................ .......
1
21
PAOZZ
72582
5338656
PLUNGER & BUSH ASSY ................................ .......
1
22
PAOZZ
72582
5226719
RACK, INJECTOR ................................ ...................
1
23
XDOZZ
72582
5226912
PIN, STRAIGHT, HEADLE ................................ .......
2
24
PAOZH
72582
5228608
PIN, STOP, FUEL, INJEC ................................ ........
1
UOC: DUP
25 XBOZZ 72582 5228739
SPRING, HELICAL, COMP ................................ ......
1
26 PAOZZ 72582 5226393
PIN, STRAIGHT, HEADLE ................................ .......
1
27 PAOZZ 72582 5228104
GUIDE, FOLLOWER................................ ................
END OF FIGURE
11-1
|
|
