 SECTION II
TM 5-2815-231-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM SMR
PART
NO CODE FSCM
NUMBER
DESCRIPTION AND USABLE ON CODES (UOC)
QTY
GROUP 01 ENGINE
XDFFF
61208
XA7297C
TOP POWER TAKE OFF................................ .........
1
1
XDFZZ
61208
A4342A
COVER, TOP ................................ ...........................
1
2
XDFZZ
61208
A2916W
PACKING, PREFORMED PIPE................................
1
3
XDFZZ
61208
B1251A
BREATHER ASSY ................................ ...................
1
4
PAFZZ
61208
M2002N
SCREW, CAP, HEXAGON H ................................ ...
10
5
PAFZZ
61208
A2007
LINK, CHAIN, SWING ................................ ..............
1
6
XDFZZ
61208
M1072
CHAIN, BREATHER................................ .................
1
7
XDFZZ
61208
M1763
CLIP ................................ ................................ .........
1
8
PCFZZ
61208
B1338A
GASKET ................................ ................................ ..
1
9
PAFZZ
61208
M2002AG
SCREW, CAP, HEXAGON H ................................ ...
2
10
PAFZZ
96906
MS35340-40
WASHER, LOCK................................ ......................
2
11
XDFZZ
61208
1144AS
SHAFT, OPERATING ................................ ..............
1
12
XDFZZ
61208
M498
SEAL, OIL ................................ ................................
2
13
PAFZZ
61208
M2002AY
BOLT, MACHINE ................................ .....................
1
14
XDFZZ
61208
A3361
LEVER, OPERATING................................ ...............
1
15
PAFZZ
61208
M1930F
NUT, SELF-LOCKING, HE ................................ .......
3
16
XDFZZ
61208
M2022Z
KEY (WOODRUFF) ................................ .................
2
17
XDFZZ
61208
1037
YOKE, CLUTCH THROWOU ................................ ...
1
18
XDFZZ
61208
9805
HOUSING ................................ ................................
1
19
PCFZZ
61208
B1829
GASKET ................................ ................................ ..
2
20
PCFZZ
61208
B5032
CARRIER, BEARING ................................ ...............
1
21
XDFZZ
61208
M174
BEARING, BALL, ANNULA ................................ ......
1
22
XDFZZ
61208
A2903M
RING, SNAP ................................ ............................
1
23
XDFZZ
61208
M2398
OIL SEAL ................................ ................................ .
1
24
XDFZZ
61208
A4886
RETAINER, BEARING ................................ .............
1
25
PAFZZ
61208
M2002BA
SCREW, CAP, HEXAGON H ................................ ...
3
26
XDFZZ
61208
M1862A
BEARING, ROLLER ................................ .................
1
27
XDFZZ
61208
B5031A
GEAR................................ ................................ .......
1
28
XDFZZ
61208
A2903X
RING, SNAP ................................ ............................
1
29
XDFZZ
61208
M1060A
BEARING, BALL, ANNULA ................................ ......
2
30
XDFZZ
61208
A2798CR
SPACER, CLUTCH ................................ ..................
1
31
XDFZZ
61208
B6043
SPIDER, CLUTCH................................ ....................
1
32
PAFZZ
61208
M2089F
BOLT, MACHINE ................................ .....................
10
33
XDFZZ
61208
B3543
PLATE, BOTTOM ................................ ....................
1
34
PAFZZ
61208
M2004C
SCREW, CAP ................................ ..........................
3
35
PAFZZ
61208
1930F
NUT, HEX ................................ ................................
2
36
XDFZZ
61208
117C8A
COLLAR................................ ................................ ...
1
37
XDFZZ
61208
120C8
SPACER, PLATE ................................ .....................
2
38
XDFZZ
61208
M2002BB
SCREW, CAP, HEXAGON H ................................ ...
2
39
XDFZZ
61208
B3548
SLEEVE SLIDING ................................ ....................
1
40
XDFZZ
61208
B1319A
RING, ADJUSTING ................................ ..................
1
41
XDFZZ
61208
B1296
PIN, ADJUSTING ................................ .....................
1
42
XDFZZ
61208
A2700AA
SPRING ................................ ................................ ...
1
43
XDFZZ
61208
B3549
PLATE, FLOATING ................................ ..................
1
44
XDFZZ
61208
B1293
LEVER ................................ ................................ .....
3
45
XDFZZ
61208
B1295C
LINK, LEVER ................................ ...........................
6
46
XDFZZ
61208
B1537N
PIN, LEVER ................................ .............................
3
47
XDFZZ
61208
B1536A
PIN, LEVER LINK................................ .....................
3
4-1
|
|
