BRANCHED Electrical POWER CABLE ASSEMBLY (DETECTOR POWER). |
|
||
| ||||||||||
|
|
 TM 3-6665-329-13&P
3-51 BRANCHED Electrical POWER CABLE ASSEMBLY (DETECTOR POWER).
(9) Unscrew screw (8) and open cable cover assembly (9).
(10) Remove cable labeled DETECTOR POWER from dummy connector (10).
(11) Pull DETECTOR POWER cable through bushing (11) from inside
CABLE STORAGE compartment.
(12) Cut lacing and tying tape from termial.
3-115
|
|
