DUMMY CONNECTOR (DETECTOR POWER CABLE) (CONT). |
|
||
| ||||||||||
|
|
 TM 3-6665-329-13&P
3-48 DUMMY CONNECTOR (DETECTOR POWER CABLE) (CONT).
Installation.
b.
(1)
Install dummy connector (7) using four screws (4), Iockwashers (6), nuts (5).
(2)
Install DETECTOR POWER CABLE (3) on dummy connector (7).
(3)
Put remaining cables in CABLE STORAGE.
(4)
Close cable cover assembly and secure with screw (1).
(5)
Install panel assembly and lid (para 3-11c steps 4 thru 8 and 20).
3-106
|
|
