 TM 3-6665-329-13&P
This Task covers:
Removal.
a.
b.
Installation.
INITIAL SETUP
Tools: Electronic equipment tool kit TK-105/G
a.
Removal.
(1) Remove lid (para 3-11b steps 1 and 2).
(2) Push in and release three fasteners (1) and open accessory shelf (2).
( 3 ) R e m o v e bellows and p
( 4 ) R e m o v e screw (4) and
b.
Installation.
(1)
Position clip (5) over mounting hole, and between raised areas,
(2) Secure clip with screw (4).
(3) Replace bellows and pump (3).
(4) Close accessory shelf (2) and secure three fasteners (1).
(5) Install lid (para 3-11c step 20).
3-54
|
|
