Table 3-1. Organizational Preventive Maintenance Checks and Services Semiannual Schedule |
|
||
| ||||||||||
|
|
 TM 11-7035-203-23
Table 3-1.
Organizational Preventive Maintenance Checks
and Services Semiannual Schedule
Equipment Will Be
Reported Not Ready/
Procedures
Item
Item To Be
Available If:
No.
Inspected
1
Tape Cleaner
Clean tape cleaner interior
as follows:
1. Power off tape cleaner and
pull power cord plug from
outlet.
2. Remove rear cover.
CAUTION
Work carefully while clean-
ing. Clean thoroughly but do
not damage components, wiring
or brackets.
3. Vacuum metal surfaces,
wiring and components using
soft-bristled, brush-type
nozzle.
4. Loosen dust and dirt in
corners, crevices and between
components using a small,
soft-bristled brush. Vacuum
up loosened dust and dirt.
WARNING
Isopropyl alcohol is flam-
mable. Keep away from heat
and open flame.
CAUTION
Use isopropyl alcohol Spar-
ingly. Alcohol can damage
some components and cause
corrosion on connector con-
tracts.
3-3
|
|
