Maintenance code - TM-11-6625-3065-24P0005

TM 11-6625-3065-24P

Code

Definition

XC -- Installation drawing, diagram, instruction sheet, field service drawing, that is identified by manufacturer's part

number.

XD -- A support item that is not stocked. When required, item will be procured through normal supply channels.

NOTE

Cannibalization or salvage may be used as a source of supply for any items source coded above

except those coded XA and aircraft support items as restricted by AR 750-1.

(2) Maintenance code. Maintenance codes are assigned to indicate the levels of maintenance authorized to

USE and REPAIR support items. The maintenance codes are entered in the third and fourth positions of the Uniform

SMR Code format as follows:

(a) The maintenance code entered in the third position will indicate the lowest maintenance level

authorized to remove, replace, and use the support item. The maintenance code entered in the third position will indicate

one of the following levels of maintenance.

Code

Application/Explanation

C -- Crew or operator maintenance performed within organizational maintenance.

-- Support item is removed, replaced, used at the organizational level.

-- Support item is removed, replaced, used at the direct support level.

-- Support item is removed, replaced, used at the general support level.

-- Support items that are removed, replaced, used at depot, mobile depot, specialized repair activity only.

(b) The maintenance code entered in the fourth position indicates whether the item is to be repaired and

identifies the lowest maintenance level with the capability to perform complete repair (i.e., all authorized maintenance

functions). This position will contain one of the following maintenance codes:

Code

Application/Explanation

O -- The lowest maintenance level capable of complete repair of the support item is the organizational level.

-- The lowest maintenance level capable of complete repair of the support item is the direct support level.

-- The lowest maintenance level capable of complete repair of the support item is the general support level.
