 SECTION II
TM 5-2815-231-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM SMR
PART
NO CODE FSCM
NUMBER
DESCRIPTION AND USABLE ON CODES (UOC)
QTY
GROUP 01
ENGINE
LUBE OIL RELIEF VALVE AND
REGULATOR
1
PCHZZ
72582
5117269
GASKET ................................ ................................ ..
2
2
PAHZZ
72582
103321
WASHER,LOCK................................ .......................
6
3
PAHZZ
96906
MS90728-62
SCREW,CAP,HEXAGON H ................................ .....
4
4
XDHZZ
72582
8921088
REGULATOR,OIL PRESS ................................ .......
1
5
PCHZZ
72582
5123240
GASKET ................................ ................................ ..
1
6
XDHZZ
72582
5102814
VALVE, RELIEF ASSY................................ .............
1
7
PAHZZ
72582
5148480
SCREW,CAP,HEXAGON H ................................ .....
2
END OF FIGURE
33-1
|
|
