 SECTION II
TM 5-2815-231-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM SMR
PART
NO CODE FSCM
NUMBER
DESCRIPTION AND USABLE ON CODES (UOC)
QTY
GROUP 01 ENGINE
FIG. 6 GOVERNOR
XDOOF
72582
5102825
GOVERNOR, DIESEL ENG ................................ .....
1
1
PBOZZ
72582
186687
BOLT 1/4 IN-20 ................................ .......................
1
2
PBOZZ
96906
MS35338-44
WASHER, LOCK................................ ......................
1
3
PBOZZ
72582
5102862
LEVER ................................ ................................ .....
1
4
PBOZZ
72582
5108775
SPRING, HELICAL, TORS ................................ .......
1
5
PBOZZ
72582
5153060
WASHER, FLAT................................ .......................
1
6
PBOZZ
72582
5144177
WASHER, SHOULDERED A................................ ....
1
7
PBOZZ
72582
453007
BOLT, ASSEMBLED WASH ................................ ....
1
8
XDOZZ
72582
453007
COVER ASSY ................................ ..........................
1
9
PCOZZ
72582
8924869
GASKET ................................ ................................ ..
1
10
PCOZZ
72582
5102471
SHAFT, SHOULDERED ................................ ...........
1
11
PCOZZ
72582
5126499
GASKET ................................ ................................ ..
1
12
PBOZZ
72582
5104592
CLAMP, HOSE................................ .........................
4
13
PCOZZ
72582
5104527
HOSE, PREFORMED 1 IN IDX ...............................
2
14
XDOZZ
72582
5124426
HOUSING ASSY ................................ ......................
1
15
PBOZZ
02978
20275
WASHER, FLAT................................ .......................
2
16
PBOZZ
72582
272545
SCREW, CAP, HEXAGON X 5-1/4 IN .....................
1
17
PBOZZ
96906
MS27183-12
WASHER, FLAT................................ .......................
8
18
PBOZZ
96906
MS35338-45
WASHER, LOCK................................ ......................
9
19
PBOZZ
72582
179827
SCREW, CAP, HEXAGON H 5/16 IN - 18...............
8
X 2 1/4................................ ................................ ......
20
PBOZZ
96906
MS90728-46
BOLT, MACHINE X 4 IN................................ ..........
1
21
PBOZZ
72582
9417926
SCREW, ASSEMBLED WAS................................ ...
7
22
PBOZZ
96906
MS90728-46
BOLT, MACHINE 3-1/2 IN ................................ ......
2
23
XDOZH
72582
5139262
ANGLE UNIT, CAM CONT ................................ .......
1
24
PCOZZ
72582
5152944
GASKET ................................ ................................ ..
1
25
PBOZZ
72582
5137276
RETAINER, SPRING, GOV ................................ ......
1
26
PAOZZ
72582
5136590
SHIM .010 IN................................ ............................
6
27
PAOZZ
72582
5136591
SHIM .078 IN................................ ............................
3
28
PAOZZ
72582
5174430
RETAINER STOP, GOVER................................ ......
1
29
PBOZZ
72582
5171784
STOP, GOVERNOR................................ .................
1
30
PAOZZ
72582
5122270
SPRING, HELICAL, COMP ................................ ......
1
31
PBOZZ
72582
5117932
PLUNGER................................ ................................
1
32
PBOZZ
72582
5152939
SEAT, HELICAL COMPRE................................ .......
1
END OF FIGURE
6-1
|
|
